Hikvision DS-2CV2Q01EFD-IW Bangladesh
Hikvision DS-2CV2Q01EFD-IW (1.0MP) Mini PT IP Camera (Wi-Fi & Built in Microphone & Speaker)
Call for Price Add to cart

Hikvision DS-2CV2Q01EFD-IW (1.0MP) Mini PT IP Camera (Wi-Fi & Built in Microphone & Speaker)

Call for Price

Up to 1.0 megapixel high resolution
Two video streams
2.8mm fixed lens
Digital Wide Dynamic Range
3D Digital Noise Reduction
Build-in microphone and speaker, support two-way audio
Support on-board storage, up to 128GB
Up to 5 m IR range
Built-in Wi-Fi
DC 5V ± 10 %, micro USB interface
? Warranty: One Year

Hikvision DS-2CV2Q01EFD-IW Bangladesh

Camera
Image Sensor:|1/4″ progressive scan CMOS
Min. Illumination:|0.02Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time:|1/3 s to 1/100,000 s
Slow shutter:|Support
Lens:|2.8mm, horizontal field of view 92°
Lens Mount:|M12
Day& Night:|IR cut filter with auto switch
Wide Dynamic Range:|Digital WDR
Digital noise reduction:|3D DNR
Compression Standard
Video Compression:|H.264
H.264 code profile:|Baseline Profile/Main Profile
Video bit rate:|32Kbps~8Mbps
Audio Compression:|G.711/G.722.1/G.726/MP2L2
Audio bit rate:|64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Max. Image Resolution:|1280 × 720
Main Stream:|50Hz: 25fps (1280 × 720)
60Hz: 30fps (1280 × 720)
Image Settings:|Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC:|Yes, zone configurable
ROI:|Support 1 fixed region for each stream
Day/Night Switch:|Support auto/scheduled
Network
Alarm Trigger:|Video tampering, alarm input, alarm output, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols:|TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv6, Bonjour, SMTP, 802.1x
Interface
Audio:|Internal Microphone and Speaker
Communication Interface:|1 RJ45 10M / 100M Ethernet interface
On-board storage:|Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:|Yes
Wi-Fi Specification (-W)
Wireless Standards:|IEEE802.11b, 802.11g, 802.11n
Frequency Range:|2.4 GHz ~ 2.4835 GHz
Channel Bandwidth:|20/40MHz Support
Security:|64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmission Rate:|11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps
Wireless Range:|50m(depend on environment)
Protocols:|802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM
General
Memory Card:|DS-2CV2Q01FD-IW: no memory card included
DS-2CV2Q01FD-IW/16G-T: includes a 16 GB memory card
DS-2CV2Q01FD-IW/32G-T: includes a 32 GB memory card
DS-2CV2Q01FD-IW/64G-T: includes a 64 GB memory card
Operating Conditions:|-10°C ~ 40°C (14°F ~ 104°F), Humidity 95% or less (non-condensing)
Power Supply:|DC 5V ± 10 %, micro USB interface
Power Consumption:|Max. 7W
IR Range:|Up to 5 meters
Dimensions:|Φ 82.4 × 113.6 mm (Φ 3.25′ × 4.47′)
Weight:|Approx. 510g (1.12 lb)
